Mini Intel Edison Console USB-TTL Expansion Board Development Module for DIY
Description:
The Intel® Edison is an ultra small computing platform that will change the way you look at embedded electronics. Each Edison is packed with a huge amount of tech goodies into a tiny package while still providing the same robust strength of your go-to single board computer. Powered by the Intel® Atom™ SoC dual-core CPU and including an integrated WiFi, Bluetooth LE, and a 70-pin connector to attach a veritable slew of shield-like “Blocks” which can be stacked on top of each other. It’s no wonder how this little guy is lowering the barrier of entry on the world of electronics!
The Console Block is one of the simplest ways to power and communicate with an Intel® Edison. This is a minimal solution to get started using the Intel® Edison. This board can supply 4V and up to 1.5A of current to power the Edison passed through it’s VSYS line and any other expansion boards you may add to your stack.
If you are looking to add a little more stability to your Intel® Edison stack, check out this Hardware Pack. It will provide you with increased mechanical strength for stacking Blocks on your Edison!
Schematic: Click here
Eagle Files: Click here
Console Block Hookup Guide: Click here
Intel® Edison Tutorials: Click here
Intel® Edison Product Brief: Click here
Getting Started: Click here
Software Downloads: Click here
Board Support Package: Click here
GitHub (Design Files): Click here
Package included:
- 1 x Expansion Board
