NK-C6 DAC Decoder Digital To Analog Audio Hifi Headphone Amplifier w/ Interface For Toslink Coaxial

DAC Decoder, Headphone Amplifier

NK-C6 DAC Decoder Digital To Analog Audio Hifi Headphone Amplifier w/ Interface For Toslink Coaxial

Introduction:
This DAC is specially designed for home or professional audio switching. It converts coaxial or digital audio signals for Toslink into analog L/R audio, and can be connected to external devices such as amplifiers through standard RCA-type jacks. It can also output by 3.5mm headphone jack, connect to high-fidelity headphones, the converter is small and easy to install, built-in high-fidelity amplifier chip, headphones and RCA output port can easily launch 16-300 ohm high-fidelity headphones. The product supports power off, volume adjustment, easier to adapt to different sources, different environments. The product also supports for Toslink input to Toslink, coaxial output, coaxial input to for Toslink, coaxial output, can adapt to more digital audio amplifier interfaces.

High compatibility, support various network players and for Apple boxes.

Support 32/44.1, /48/49/192KHZ sampling rate, and support 8-300 ohm headphones and speakers.

Features:
- Convert coaxial or digital audio signal for Toslink to analog L/R audio
- Support sampling rate of 32kHZ, 44.1kHZ, 48kHZ, 96kHZ and 192kHZ, up to 24 bit resolution
- 24-bit S/PDIF input bit stream on left and right channels
- Support 16-300 ohm high-fidelity headset
- Support shutdown
- Support volume adjustment
- Support for Toslink input to coaxial output
- Support for Toslink output coaxial input
- Provide no electromagnetic noise transmission
- Easy to install and simple to operate

Specifications:
- Input audio: coaxial or digital audio for Toslink
- Output audio: L/R, earphone, for Toslink
- Input audio connector: for Toslink, 1xRCA (coaxial)
- Output analog audio connector: 2xRCA (R/L) and 3.5mm earphone
- Output digital audio connector: for Toslink, 1xRCA (coaxial)
- Sampling rate: 32, 44.1, 48, 96 and 192Khz, up to 24-bit resolution
- Maximum output power: 16Ω, 200mW; 300Ω, 20mW
- Distortion: <0.01% (10mW)
- Headphone impedance: 16Ω~300Ω
- Frequency response: 10Hz~48KHz
- Size: 8.5x9.6x2.8cm (LxWxH)
- Net weight: 130g
- Working temperature: 0℃ to 70℃
- Working humidity: 10% to 85% RH (non-condensing)
- Storage temperature: -10℃ to 80℃
- Storage humidity: 5% to 90% RH (non-condensing)
- External power requirements: 5V DC at 500mA
- Power consumption: 0.5 watts (maximum)

Package Included:
- 1 x Set of Headphone Amp DAC
