P124M-4201 Made-in-China 275A Motor Controller Compatible-Curtis 1204-004 1204-036 1204M-4201

P124M-4201 Made-in-China 275A Motor Controller Compatible-Curtis 1204-004 1204-036 1204M-4201

Attention:
- Customers need to choose accelerator mode(0-5v, 0-5k, 5k-0) and voltage (24V/36V optional), please leave us a message.

Product Description:
- P124M-4201 China-made controller is a DC series winding motor speed controller, compatible-CURTIS 1204M-4201 controller (and old original 1204 controllers like 1204-004, 1204-036, etc.)
- Made by a Chinese manufacturer, the P124M-4201 controller is compatible-CURTIS programming devices, and the quality had been approved by many vehicle makers. All parameters of P124M-4201 are the same as its original version of 1204M-4201
- By defaut, we will deliver the controller with default setting of 275A / 0-5kΩ (Throttle Type = "0"). For better applying the controller to your system, the buyer should confirm with the seller the battery system voltage and the throttle type (0-5kΩ, 5k-0Ω or 0-5V)
- P124M-4201 DC Series Motor Controller
- Compatible-CURTIS 1204M-4201
- 36V/24V- 275A
- Compatible-Curtis1204-004 and many other 1204 controllers
- New in box

Key Features:
- Controller Model: P124M-4201 (Compatible-Curtis 1204M-4201)
- Nominal Battery Voltage (Volts): 24V/36V
- 2 Minute Current Rating (amps): 275
- 5 Minute Current Rating (amps): 200
- 1 Hour Current Rating (amps): 125
- Plug Braking (A2 Busbar): Yes

Package List:
- 1 x 275A Motor Controller

Note:
- If throttles are needed, please contact us for details and prices. Thank you!
- Battery is not included.
