PA1 Power Amplifier Module Power Amp Module Maximum ±10V/1A Output 50K Bandwidth For SIG852 S02
PA1 Parameters:
- Number of channels: 1
- Bandwidth: 50K Hz
- Input voltage range: -5V to +5V
- Voltage magnification: X1, X2 and X4
- Output voltage range: -10V to +10V
- Maximum output current: 1A
- Module power supply: 12V, 2A
- Size: 85 x 55 x 20mm/3.3 x 2.2 x 0.8"
Applications:
The output power of signal generators is generally relatively small, such as LOTO's SIG852 arbitrary waveform generator or S02 signal source module, the voltage range and load capacity are limited. In some applications, it may be necessary to use output signal to drive high-power actuators such as solenoid valves and motors. At this time, it is necessary to amplify the signal of signal generators. The function of the PA1 module is to amplify the power.
Package Included:
- 1 x Set of PA1 Power Amplifier Module
