Paint Coating Thickness Gauge Meter 0-3000μm for Coating Thickness within 3mm EC-770X

Paint Coating Thickness Gauge Meter 0-3000μm for Coating Thickness within 3mm EC-770X

Description:
The EC-770X coating thickness gauge is for simultaneous measurement of non-magnetic coatings (such as paint, ceramics, chrome and so on) on magnetic substrate surfaces (steel, iron, etc.) and non-conductive surfaces on non-magnetic metal substrates coating (such as paint, anodized film and the like).

The instrument is equipped with a high-precision dual probe, using electromagnetic induction and eddy current effects, fully automatic detection of substrate properties, and calculation of coating thickness. What’s more, it can rapidly display results via the LCD screen.

At the same time, measurement data can be saved in groups and displayed in real time. Users can set top and lower alarm values, zero calibration, and multi-point calibration for each group. New zero calibration and multi-point calibration make it easy to calibrate at any time. Standardized the menu makes sure that it is easy to operate.

Features:
- Data storage up to 2000
- USB transfer data to PC
- Measurement range up to 3,000μm
- Dual-core 32 RAM processor for higher efficiency
- 2 measure mode: Single/Continuous
- 2 group model: DIR (direct)/GEN (General)
- 3 probe mode: Auto/Magnetic/Eddy current
- Auto temperature compensation ensures accuracy
- Application: To measure non-magnetic coatings (painting, enamel, chrome etc) on steel AND non-conductive coatings (painting, anodizing) on non-ferrus surface (Aluminum, zinc or copper etc).

Specifications:
- Model Number: EC-770X
- Magnetic Induction:√
- Eddy Current Effect:√
- Measurement Range:
  F: 0~3000μm
  N: 0~3000μm
- Measurement Accuracy:
  F: 2%+1μm
  N: 2%+1μm
- Resolution:
  0μm~99.9μm (0.1μm)
  100μm~999μm (1μm)
  >1000μm (0.01mm)
- Data Storage: 2000 Readings
- Real-time Data Statistics:√
- CPU: 32 Bits ARM
- Automatic Temperature Compensation:√
- Reset Zero:√
- Multi-Point Calibration:√
- Measurement Data Grouping:√
- One Key Data Clear (Press to delete):√
- One Key Group Data Clear (Press and hold to delete):√
- Multi-Level Power Indicator:√
- Digital Display: 128*128 Dots
- Auto Power Off:√
- USB Interface:√
- Red Backlight Alarm: √
- Display Screen Inversion: √
- Size: 113 x 53 x 24mm
- Material: ABS
- Certificate: CE, ROHS, FCC, GB/T 4956-2003, GB/T 4957-2003
- Storage Temperature: -10°C~60°C
- Operating Temperature: -10°C~60°C

Note:
- It is suitable for detection thickness of coatings ≤3mm.
- Please note that batteries are not included in this package. Please purchase 2*1.5V AAA batteries separately. Thank you!
