PIX ULBOX NEO-M8N GPS Module High Precision for Multicopter FPV Photography
Description:
- The new version GPS data cable interface is DF13 gluey shell, has lock up buckle function. If you don't want it locked, please chop off the triangle lock catch
- If it can not match with old version socket, please cut the protrude part open by knife
- This GPS wires are all terminal interface of DF13, if you change to gluey shell, you need to use it with DF13 gluey shell.
- Built in electric compass version can be used at APM 2.5/ 2.6, compatible with PIX flight control
- 2.5 needs to be cut off built in electric compass jumping cable
GPS cable definition:
- Red vcc Black gnd
- Green RX Yellow TX
Compass cable definition:
- Orange SCL White SDA
NEO-M8N:
- NEO-M8N series provides high sensitivity and maximum collection time, meanwhile keeping the lowest system power.
- And i t provides best performance and easy for RF integration
