Product Description: The PLC adopts industrial grade anti-jamming strong 32 bit MCU,and the running speed is far beyond the original FX1N,X0~X5 high speed input the highest 12K,1 AB,support SFC,support for monitoring (write) mode,support all kinds of text screen,touch screen,memory clear,support special encryption support (as long as the keyword input after 12345678 there is no power after reading,can only download the program to achieve the purpose of user program can not break
Specification:
- Mode:FX1N-24MT pulse output
- Working Power:DC 24V
- Input/Output:14 input/10 output
- Input signal:0V effective/Low level/NPN
- Output signal:low level,effective,COM connect 0V
- Rated current:24V 7A,external add 3A free-wheeling diode
- RS-485:standard RS-485 interface,MODBUS RTU protocol.
- High speed counting:6 channel counter default 12K optional 100K(1 channel AB count)
- High speed pulse:2 channel 20K
- Touch screen:can connect all touch screen on the market
- Connect text:can connect text monitor
- Program software:GX-Developer,GX-WORK2
- Download cable:DB9 serial/standard 232 communication port
- Program steps:8000 steps
- Size:121x87x22mm
Package List:
- 1 x Control Board
- 1 x User manual
