SCB-68A 782536-01 68-Pin Screw Terminal Block Shielded Connector Block for NI National Instruments
Description:
68-Pin Female Screw Terminal to 68-Pin Female D-SUB, DIN-Rail, Shielded I/O Connector Terminal Block—The SCB-68A provides a shielded I/O connection for interfacing I/O signals to plug-in data acquisition devices with 68-pin connectors. This Terminal Block combines with shield cables to provide low-noise signal termination. The SCB-68A incorporates a completely redesigned mechanical enclosure with a magnetic removable lid, DIN-rail mount compatibility, and a resettable fuse. It is compatible with single- and dual-connector Multifunction I/O with 68-pin connectors. The SCB-68A also includes two general-purpose breadboard areas and an onboard cold-junction compensation sensor.
Features:
- Shielded I/O terminal block for 68-pin NI X-series, M-series, E-series, B-series, S series and R-series DAQ devices
- Screw terminals for simple I/O connections
- 2 universal breadboard areas
- On-board cold-junction temperature compensation sensor for low-cost thermocouple measurements
- Movable magnetic cover, DIN rail bracket and resettable fuse
- For high-precision thermocouple measurements. SCC and SCXI signal conditioning can be used.
Package Included:
- 1 x Set of Terminal Block
