Skylab GPS Module Receiver SKM58 with Embedded GPS Antenna

Availability: Out Of Stock

  • Price:$22.95
  • Price in reward points: 230 Reward Points: 2
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $22.49 $22.03 $21.34 $20.43 Contact US
Quantity:
Buy it now Add cart

You might like

Skylab GPS Module MT3329 SKM53 with Embedded GPS Antenna Arduino Compatible

Skylab GPS Module MT3329 SKM53 with Embedded GPS Antenna Arduino Compatible

$28.49

(0)
SI4463-SMT Wireless Transceiver Module With Springs Antenna

SI4463-SMT Wireless Transceiver Module With Springs Antenna

$7.79

(0)
HF231 APP Bluetooth Audio Receiver Bluetooth 5.0 Receiver + Remote Controller + Bracket Unassembled

HF231 APP Bluetooth Audio Receiver Bluetooth 5.0 Receiver + Remote Controller + Bracket Unassembled

$13.56

(0)
GEPRC Cinebot30 HD Runcam Link Wasp + ELRS2.4 FPV Drone with System for Quadcopter FPV

GEPRC Cinebot30 HD Runcam Link Wasp + ELRS2.4 FPV Drone with System for Quadcopter FPV

$402.43

(0)
BT-877 Highly Integrated Low Power Half-duplex Wireless Transmission Module Set with Transmitter and Receiver

BT-877 Highly Integrated Low Power Half-duplex Wireless Transmission Module Set with Transmitter and Receiver

$166.02

(0)
Serial TTL RS232 to 802.11 b/g/n Converter Embedded WiFi Module CE FCC

Serial TTL RS232 to 802.11 b/g/n Converter Embedded WiFi Module CE FCC

$52.95

(0)
SI4463 Wireless Transceiver Module With SMA Antenna 410-440M 2000M

SI4463 Wireless Transceiver Module With SMA Antenna 410-440M 2000M

$8.96

(0)
HF231 APP Bluetooth 5.0 Receiver Board + Remote Controller + Bracket + Radio Antenna Unassembled

HF231 APP Bluetooth 5.0 Receiver Board + Remote Controller + Bracket + Radio Antenna Unassembled

$13.99

(0)

Skylab GPS Module Receiver SKM58 with Embedded GPS Antenna

SKM53 Series with embedded GPS antenna.It based on MediaTek 3329 single-chip architecture.SKM53 can be applied in a portable device and receiver like PND, GPS mouse, car holder, personal locator, speed camera detector and vehicle locator.

Features:
- Ultra high sensitivity: -165dBm
- 22 tracking/66 acquisition-channel receiver
- WAAS/EGNOS/MSAS/GAGAN support
- NMEA  protocols (default speed: 9600bps)
- Internal back-up battery and 1PPS output
- One serial port and USB port (option)
- Embedded patch antenna 12 x 12 x 4.0 mm
- Operating temperature range: -40 to 85
- RoHS compliant (Lead-free)
- Tiny form factor 20.5mm x12.8mm x 7.8mm

Specifications:

Receiver Type

L1 frequency band, C/A code
22 Tracking / 66 Acquisition-Channel

Sensitivity

Tracking
Acquisition

-165dBm
-148dBm

Accuracy



Position
Velocity
Timing (PPS)

3m 3D RMS without SA
0.1m/s without SA
60ns RMS

Acquisition Time

Cold Start
Warm Start
Hot Start
Re-Acquisition

36s
33s
1s
<1s

Power Consumption

Tracking
Acquisition
Sleep/Standby

<30mA @ 3V Vcc
40mA
TBD

Navigation Data Update Rate

1Hz



Operational Limits

Altitude
Velocity
Acceleration

Max 18,000m
Max 515m/s
Less than 4g
Antenna Specifications

OutlineDimension
Center Frequency
Bandwidth
Impedance
Axial Ratio
Polarization

18.2 x 18.2 x 4.0 mm
1575 ± 3 MHz
10 MHz min
50 Ω
3 dB max
RHCP
Mechanical requirements

Dimension
Weight

30mm x20mm x 11.4mm
9g
Power consumption

VCC
Current

5V ±5%
55mA(typical)
Environment

Operating temperature
Storage temperature
Humidity

40 ~ +85 (w/o backup battery)
0 ~ +125
