Skypix TSN44W Wireless Wifi Handheld Portable A4 Document Photo Scanner 900 DPI
Description:
4.8 How to use WIFI function
You can use the facilities with built-in WIFI module (such as PCs, laptops, IPAD, IPHONE and so on) to view the scanned images. Follow the steps below:
Connect your WiFi Scanner
1. Turn on your scanner and switch to WiFi mode
2. The blue LED flashes to indicate the WiFi warming up. It will take around 15-20 seconds for WiFi to warm up and become connectable which the LED will stop flashing
3. Switch to other mode to turn off the WiFi anytime.
Notes
1）WiFi will drain your camera battery. Switch to other mode if you are not using it.
2） Your WiFi scanner can only connect to one device each time.
Connect the camera to your computer
1. Turn to WiFi mode of your scanner
2. Go to network setting of your PC and choose WiFi setting. Search the network, find and click “MAGICWAND”
3. Enter password “123456789” and you can connect to your camera.
4. Open your Internet browser and input “10.10.1.1”. You can view the jpeg or pdf stored in your scanner
Connect the camera to your smart device (browser)
1. Turn to WiFi mode of your scanner
2. Go to network setting of your mobile device and choose WiFi setting. Search the network, find and click “MAGICWAND”
3. Enter password “123456789” and you can connect to your camera.
4. Open your Internet browser and input “http://scanner.local”. You can view the photos and videos stored in your camera.
Connect the camera to your smart device (app)
1. Search MagicWand app at the App store.
2. Download and install the app to your smart device
3. Turn to WiFi mode of your scanner
4. Go to network setting of your PC and choose WiFi setting. Search the network, find and click “MAGICWAND”
5. Enter password “123456789” and you can connect to your camera.
6. Open your app.
7. You can refer to app page for the detailed operation description.
|
Image sensor |
A4 Color Contact Image Sensor |
|
Number of sensor |
5136 dots(1st~5104 dots available) |
|
Resolution |
Low resolution : 300x300 dpi Middle resolution: 600x600 dpi High resolution: 900x900 dpi |
|
Maximum scanning speed for A4 size document |
High resolution with color≥12s; Hign resolution with mono≥10s Medium resolution with color≥8S ; medium resolution with mono ≥6S; Low resolution with color≥3S; Low resolution with mono≥2S; |
|
Capacity (Based on 1GB micro SD card. Scan A4 size file, the quantity of scans varies depending on the content complexity) |
900dpi color: 300pcs/JPG or PDF (Min.) 900dpi mono:320 pcs/JPG or PDF (Min.) 600dpi color: 640 pcs/JPG or PDF (Min.) 600dpi mono: 700 pcs/JPG or PDF (Min.) 300dpi color: 1600 pcs/JPG or PDF (Min.) 300dpi mono: 1800 pcs/JPG or PDF (Min.) |
|
Scan width |
212mm |
|
Scan length |
300DPI:98"(max);600DPI: 45";(max);900DPI:35"(max) |
|
File format |
JPEG/PDF |
|
LCD |
Scanning status display |
|
Auto Power Off |
3 Minutes |
|
USB Port |
USB 2.0 high speed |
|
External memory |
Micro SD Card |
|
Standard Battery |
2XAA alkaline batteries (not included) |
Computer system minimum requirement
|
Operating System |
Windows 7 / Vista / XP and Mac OS 10.4 or above (direct plug-in, driver installation not required) |
|
CPU |
Pentium Ⅲ or above |
|
RAM |
At least 256MB |
|
Interface |
USB port |
