SunnySky X2206S 2380KV Brushless Motor CCW Thread for FPV Multicopter Quadcopter
Specification:
- Model: X2206S
- KV: 2380
- Stator diameter: 22mm
- Stator thickness: 6mm
- Configuration: 12N14P
- No.load current@10V: 1A
- Motor resistance: 54mOhm
- Max. continuous current: 25A/15s
- Max. continuous power: 370W
- Weight: 31g
- Outside diameter: 27mm
- Shaft diameter: 3mm
- Body length: 16.6mm
- Overall shaft length: 31.2mm
- Max. Lipo cell: 2-4S
- Motor thread: CCW
- Suitable for FPV multi-rotor, mini quadcopter.
Package included:
- 1* SunnySky X2206S 2380KV brushless motor
