SUNNYSKY X2814 1100KV Outrunner Brushless Motor for Multicopter
Specfications:
- Model:X2814-1100KV
- KV (rpm/v): 1100
- Non-load current: 10V/1.1A
- Weight: 106g
- Diameter: 35mm
- Length : 52.1mm/ 34mm (with shaft/ without motor shaft)
- Motor Shaft Diameter(mm): 4
- Prop adaptor output shaft diameter: 6mm
| X2814 KV1100 | |||||
| Testing Data (for reference only): | |||||
| Propeller Type | Voltage | Current | Thrust(G) | Power（W） | G/W Ratio |
| Apc11X7 | 7.4V | 19.6A | 1.05kg | 145.04 | 7.23 |
| 8.5V | 25.5A | 1.4kg | 216.75 | 6.45 | |
| 10V | 30.2A | 1.65kg | 302 | 5.46 | |
| 11V | 34.3A | 1.86kg | 377.3 | 4.92 | |
| 11.3V | 35.6A | 1.93kg | 402.28 | 4.79 | |
| EMP11X5.5 | 7.4V | 18.4A | 1.03kg | 136.16 | 7.56 |
| 8.5V | 22.3A | 1.3kg | 189.55 | 6.85 | |
| 10V | 27.6A | 1.62kg | 276 | 5.86 | |
| 11V | 31.9A | 1.88kg | 350.9 | 5.35 | |
| 11.3V | 33.4A | 1.95kg | 377.42 | 5.16 | |
| EMP12X6 | 7.4V | 26.4A | 1.3kg | 195.36 | 6.65 |
| 8.5V | 30.9A | 1.6kg | 262.65 | 6.09 | |
| 10V | 38.1A | 1.98kg | 381 | 5.19 | |
| 11V | 43.5A | 2.3kg | 478.5 | 4.8 | |
| EMP9X6 | 10V | 22.9A | 1.25kg | 229 | 5.45 |
| 11V | 26.3A | 1.4kg | 289.3 | 4.83 | |
| 12V | 29.4A | 1.62kg | 352.8 | 4.59 | |
| 13V | 32.6A | 1.8kg | 423.8 | 4.24 | |
| 14V | 36.4A | 2.0kg | 509.6 | 3.92 | |
| 14.8V | 38.9A | 2.1kg | 575.72 | 3.64 | |
