SUNNYSKY X2814 1250KV Outrunner Brushless Motor for Multicopter
Specfications:
- Model:X2814-1250KV
- KV (rpm/v): 1250
- Non-load current: 10V/1.1A
- Weight: 106g
- Diameter: 35mm
- Length : 52.1mm/ 34mm (with shaft/ without motor shaft)
- Motor Shaft Diameter(mm): 4
- Prop adaptor output shaft diameter: 6mm
| X2814 KV1250 | |||||
| Testing Data (for reference only): | |||||
| Propeller Type | Voltage | Current | Thrust(G) | Power（W） | G/W Ratio |
| EMP11X5.5 | 7.4V | 26.3A | 1.45kg | 194.62 | 7.45 |
| 8.5V | 31.2A | 1.62kg | 265.2 | 6.1 | |
| 10V | 38.8A | 1.86kg | 388 | 4.79 | |
| 10.5V | 41.2A | 1.98kg | 432.6 | 4.57 | |
| 11V | 43.2A | 2.1kg | 475.2 | 4.41 | |
| EMP9X6 | 10V | 31.2A | 1.4kg | 312 | 4.48 |
| 11V | 35.5A | 1.58kg | 390.5 | 4.04 | |
| 12V | 40A | 1.78kg | 480 | 3.7 | |
| 13V | 44.3A | 2.04kg | 575.9 | 3.54 | |
| 14V | 49A | 2.15kg | 686 | 3.13 | |
| 14.8V | 53.7A | 2.38kg | 794.76 | 2.99 | |
| EMP8X5 | 10V | 24.2A | 1.04kg | 242 | 4.29 |
| 11V | 27.4A | 1.2kg | 301.4 | 3.98 | |
| 12V | 32.5A | 1.46kg | 390 | 3.74 | |
| 13V | 36.3A | 1.62kg | 471.9 | 3.43 | |
| 14V | 39.6A | 1.78kg | 554.4 | 3.21 | |
| 14.8V | 42.8A | 1.88kg | 633.44 | 2.96 | |
