TFmini Lidar Range Finder Sensor Module Single-Point Micro Ranging Module for Arduino Pixhawk Drone
Description:
With unique optical and electrical design, the product is based upon ToF (Time of Flight) principle and adopts 850nm infrared light source so as to measure distance with stability, precision, high sensitivity and high speed.
The product is built with algorithms adapted to various application environments so as to offer excellent distance measurement performances with low cost and small size. The product adopts multiple adjustable configurations for flexible use by the client, which is better to satisfy the users' demand.
Parameters:
- Indoor Operating Range: up to 12m
- FOV: 4°
- Accuracy: 1cm
- Communication Interface: UART
- Sampling Rate: 100Hz
- Input Voltage: 5V
- N.W.: 5g
Package Included:
- 1 x TFmini Lidar Range Finder Module
- 1 x Cable
