TL-560 Optical Power Meter AIO Red Light Optical Fiber 10KM
Features:
TL-560 Optical Power Meter AIO Red Light Optical Fiber 10KM
Parameters:
Power measurement range A:-70~+10/ C:-50~+26
Wavelength range nm:800~1700
Calibration wavelength: nm:850, 1300, 1310, 1490, 1550, 1625
Measurement accuracy was 3% (-10dBm, 22).
Display resolution dB linear display: 0.1%, log display: 0.01dBm
Working temperature -10 ~ +50℃
Storage temperature -20 ~ +70℃
Relative humidity (90% DEG C, being not condensed)
Optical interface FC, SC (LC ST purchase)
Power 5 AA battery
Battery continuous working hours (H120 hours)
Automatic shutdown time min10
Weight 180g
Dimensions mm:158 x 29 x 82
Red light (wavelength 650nm, power function option) 1/10/20/30/50mw optional, output 0HZ, 2HZ
Pacakge includes:
- Optical power meter x 1
- Mini bag x 1
- FC optical power meter interface x 1
- SC optical power meter interace x 1
- Red power supply FC adapting interface x 1
- Manual x 1
