Description:
Complex detection technology is currently the internationally popular new multi-function and high reliability of fire detection technology. JTF-GOM-GST601 point type hybrid heat detectors sense smoke (hereinafter referred to as detectors) is a multi-complex by the smoke detector sensors, and semiconductor temperature sensors from the process structure and the circuit structure formed together. It not only has ordinary scattering-type photoelectric smoke detector performance, and both the temperature, differential fixed temperature heat detectors performance. It is because of the smoke and temperature composite technology, which makes the detector is capable of complex national standard test fire SH3 (polyurethane plastics fire) and SH4 (n-heptane fire) burning detection and alarm. Meanwhile detector which can burn alcohol and other significant temperature rise of the fire detection and alarm, and expand the range of applications of photoelectric smoke detectors. The Promise of the signal detector to the second bus system, you can access the Hudson Bay Company production of various types of fire alarm control alarm bus. And other detectors of the detector and the Hudson Bay Company production of fully compatible, can be mixed on the same bus.
Two, JTF-GOM-GST601 point type hybrid heat detectors sense smoke characteristic:

Address coding
1.JTF-GOM-GST601 temperature detectors sense smoke directly written by an electronic encoder, project commissioning is simple and reliable.
2. microcontrollers real-time sampling data, and can save 14 historical data, curve shows track scene.
3. With drift compensation, dust accumulation newspaper dirty function.
The critical components of the self-diagnosis function.
5. Promise of two bus signals.
Three, JTF-GOM-GST601 point type hybrid heat detectors sense smoke

Technical characteristics:
1. Detector Category: A2R
2. Operating voltage: bus 24V, the allowable range: 16V ~ 28V
3. Working Current: Monitor current ≤0.6mA, alarm current ≤1.8mA
4. Alarm confirmation light: red, flashes when data logging, alarm Always
5. Encoding: electronic coding (encoding the range 1 to 242)
6. Protection area: the proposed reference point type smoke detector and point-type heat detectors setup requirements, specific parameters should be "automatic fire alarm system design specifications" (GB 50116) prevail
7. Wire: The Promise of two bus signal
8. Use of the environment:
Temperature: -10 ~ + 50
Relative humidity ≤95%, non-condensing
9. Dimensions: Diameter: 100mm height: 56mm (with stand)
10. Housing protection grade: IP22
11. The housing materials and colors: ABS Ivory
12. Weight: about 120g
13. Install pitch: 45mm ~ 75mm
14. Implementation of the standards: GB 4715-2005, GB 4716-2005
