| Quantity | 3+ units | 10+ units | 30+ units | 50+ units | More |
|---|---|---|---|---|---|
| Price /Unit | $44.83 | $43.91 | $42.54 | $40.71 | Contact US |
Half-Bridge Integrated DRSSTC Driver Set Tesla Coil Driver Board + Fan + Fuses + Fixing Accessories
$63.56
Dgm V2.1 Open Source Brushless Motor Driver with CAN-FD Module Brushless Motor & Mounting Brackets
$124.05
Dgm V2.1 Open Source Brushless Motor Driver Board Kit with Brushless Motor & Mounting Brackets
$102.67
Toro 2200KV/4P Brushless Motor for 1/10 Car
Specfications:
| Item Name | Toro 2200KV/4P BL Motor for 1/10 Car | ||
| Sensored /Sensorless | sensorless | No loading @7.2V Current | 0.8A |
| Turns | 6T | Max current | 28A |
| KV value | 2200KV | Resistance (Ω) | 0.021Ω |
| Poles | 4P | Battery range | 2-3S |
| Diameter | 35.9mm | Operation Temperature | <130C |
| Motor length | 50mm | Max Temperature | <180C |
| Extend shaft diameter | 3.17mm | Suitable car scale | 1/10 |
| Length of extend shaft | 15mm | Suitable ESC | >35A |
| Weight | 190g | Connector Type | 3.5mm |
| Thickness of lamination | 0.35mm | ||
