Toro 4300KV/4P Brushless Motor for 1/10 Car
Specfications:
| Item Name | Toro 4300KV/4P BL Motor for 1/10 Car | ||
| Sensored /Sensorless | sensorless | No loading @7.2V Current | 2.5A |
| Turns | 2T | Max current | 72A |
| KV value | 4300KV | Resistance (Ω) | 0.006Ω |
| Poles | 4P | Battery range | 2S |
| Diameter | 35.9mm | Operation Temperature | <130C |
| Motor length | 50mm | Max Temperature | <180C |
| Extend shaft diameter | 3.17mm | Suitable car scale | 1/10 |
| Length of extend shaft | 15mm | Suitable ESC | >80A |
| Weight | 190g | Connector Type | 3.5mm |
| Thickness of lamination | 0.35mm | ||
