TS932 5.8G 32CH Audio Video A/V Receiver RX w/ Channel Display for FPV Multicopter Blue
Features:
- 32 channels: Cover A, B, E bands and F band (Airwave band), 4 bands and all frequencies compactable;
- Two switching buttons: CH button for frequencies channels switching, FR button for frequencies bands switching;
- Two digits display: one for CH and the other for FR, real-time positioning which frequency band and which channel received;
- Power off memory: Replay the very last frequency band and channel
- Independent video and audio signal outputs
Specification:
- Video format supported: NTSC/PAL
- Antenna connection: RP-SMA, female (module side)
- Power input: 12V
- Working current: 200mA max
- Antenna impedance: 50Ω
- Antenna gain: 2db
- Video impedance: 75Ω
- Video format: NTSC/PAL auto
- Dimension: 55x 30 x12mm
- Weight: 40g
- Color: Blue
Package Included:
- 1 x receiver (RX)
- 1 x antenna RP-SMA male
- 1 x basic wires set
