SPECIFICATIONS
| Basic Functions | Range | Best Accuracy | |||
|---|---|---|---|---|---|
| DC Voltage | 200mV/2V/20V/200V/1000V |  (0.5%+1) | |||
| AC Voltage | 2V/20V/200V/750V | (0.8%+3) | |||
| DC Current | 2mA/20mA/200mA/20A | (0.8%+1) | |||
| AC Current | 20mA/200mA/20A | (1%+3) | |||
| Resistance | 200W/2kW/20kW/200kW/2MW/20MW/200MW | (0.8%+1) | |||
| Capacitance | 20nF/200nF/2mF/100mF | (4%+3) | |||
| Temperature (oC) | -40oC ~ 1000oC | (1%+3) | |||
| Temperature (oF) | -40oF ~ 1832oF | (1%+4) | |||
| Special Functions | |||||
| Diode |  | ||||
| Continuity Buzzer | | ||||
| Data Hold | | ||||
| Display Backlight | Auto Sensor | ||||
| Full Icon Display | | ||||
| Sleep Mode | | ||||
| Low Battery Display | | ||||
| Input Impedance for DC Voltage Measurement | Around 10MW | ||||
| Max. Display | 1999 | ||||
GENERAL CHARACTERISTICS
| Power | 9V Battery (6F22) |
| LCD Size | 59 x 25mm |
| Product Colour | Red and Grey |
| Product Net Weight | Around 275g |
| Product Size | 165 x 80 x 38.3mm |
| Standard Accessories | Test Lead, Battery, English Manual, Point Contact Temperature Probe, Test Clip |
| Optional Accessories* | Clip-On Test Lead Light (UT-TL), Built-In Test Lead Light (UT-L1), Built-In Test Lead Light Plus (UT-L2) |
| Standard Individual Packing | Gift Box |
| Standard Quantity Per Carton | 40 pcs |
| Standard Carton Measurement | Around 588 x 408 x 326 mm (Around 0.078 CBM Per Standard Carton) |
| Standard Carton Gross Weight | Around 20.5kg |
