SPECIFICATIONS
| Basic Functions | Range | Best Accuracy | |||
|---|---|---|---|---|---|
| DC Voltage | 600mV/6V/60V/600V/1000V |  (0.5%+3) | |||
| AC Voltage | 600mV/6V/60V/600V/1000V | (1%+2) | |||
| DC Current | 60mA/600mA/10A | (1.2%+3) | |||
| AC Current | 60mA/600mA/10A | (2%+5) | |||
| Resistance | 600W/6kW/60kW/600kW/6MW/60MW | (1%+2) | |||
| Capacitance | 6nF/60nF/600nF/6mF/60mF/600mF/6mF | (4%+3) | |||
| Temperature (oC) | -40oC ~ 1000oC | (1%+3) | |||
| Frequency | 6kHz/60kHz/600kHz/6MHz/60MHz | (0.05%+3) | |||
| Special Functions | |||||
| Fused 10A Range |  | ||||
| Auto Ranging | | ||||
| Diode | | ||||
| Continuity Buzzer | | ||||
| Data Hold | | ||||
| RS232C | | ||||
| Display Backlight | | ||||
| Full Icon Display | | ||||
| Sleep Mode | | ||||
| Low Battery Display | | ||||
| Input Impedance for DC Voltage Measurement | Around 10MW | ||||
| Max. Display | 5999 | ||||
GENERAL CHARACTERISTICS
| Power | 9V Battery (6F22) |
| LCD Size | 63 x 31mm |
| Product Colour | Red and Grey |
| Product Net Weight | Around 312g |
| Product Size | 177 x 73.5 x 35mm |
| Standard Accessories | Test Lead, Battery, English Manual, Point Contact Temperature Probe, Test Clip, RS232C Interface Cable, Software |
| Optional Accessories* | Clip-On Test Lead Light (UT-TL), Built-In Test Lead Light (UT-L1), Built-In Test Lead Light Plus (UT-L2) |
| Standard Individual Packing | Gift Box |
| Standard Quantity Per Carton | 40 pcs |
| Standard Carton Measurement | 595 x 400 x 326 mm (0.078 CBM Per Standard Carton) |
| Standard Carton Gross Weight | Around 26kg |
