SPECIFICATIONS
| Basic Functions | Range | Best Accuracy |
|---|---|---|
| DC Voltage | 4V/40V/400V/1000V |  (0.1%+5) |
| AC Voltage | 4V/40V/400V/750V | (1%+4) |
| DC Current | 400mA/4000mA/40mA/400mA/10A | (0.5%+10) |
| AC Current | 400mA/4000mA/40mA/400mA/10A | (1.2%+4) |
| Resistance | 400W/4kW/40kW/400kW/4MW/40MW | (0.5%+10) |
| Capacitance | 40nF/400nF/4mF/40mF/400mF/4mF/40mF | (1.5%+20) |
| Temperature(oC) | -40oC ~ 400oC | (1%+5) |
| Frequency | 4kHz/40kHz/400kHz/4MHz/40MHz/400MHz | (0.01%+3) |
| Special Functions | ||
| Fused 10A Range |  | |
| Auto Ranging | | |
| 4~20mA Loop | | |
| EF Function | | |
| Diode | | |
| Continuity Buzzer | | |
| True RMS | AC | |
| Max/Min Mode | | |
| Relative Mode | | |
| Data Hold | | |
| Full Icon Display | | |
| Sleep Mode | | |
| Low Battery Display | | |
| Input Impedance for DC Voltage Measurement | 3999 (on functions of AC Voltage, AC Current, Diode and Continuity Buzzer) 39999 (on functions of DC Voltage, DC Current, Resistance, Capacitance, Frequency, EF Function and 4-20mA Loop) | |
| Analogue Bar Graph | |
GENERAL CHARACTERISTICS
| Power | 9V Battery (6F22) |
| LCD Size | 63 x 31mm |
| Product Colour | Red and Grey |
| Product Net Weight | 320g |
| Product Size | 177 x 85 x 40mm |
| Standard Accessories | Test Lead, Battery, English Manual, Point Contact Temperature Probe, Multi-Purpose Socket, Alligator Clip |
| Optional Accessories* | Clip-On Test Lead Light (UT-TL), Built-In Test Lead Light (UT-L1), Built-In Test Lead Light Plus (UT-L2) |
| Standard Individual Packing | Gift Box |
| Standard Quantity Per Carton | 40 pcs |
| Standard Carton Measurement | 595 x 400 x 326mm (0.078CBM Per Standard Carton) |
| Standard Carton Gross Weight | Around 25kg |
