Quantity | 3+ units | 10+ units | 30+ units | 50+ units | More |
---|---|---|---|---|---|
Price /Unit | $184.25 | $180.49 | $174.85 | $167.33 | Contact US |
USB 138M-4.4G SMA Sweep Frequency Signal Source Signal Generator Simple Spectrum Analyzer
Feature:
- Output frequency range 138MHz-4.4GHz,
- Stepping: 1kHz
- Output power (for reference): 150M-3.2DBM; 250M-3.4DBM, 500M,-3.4DBM; 750M-2.8DBM, 1000M-3.4DBM;
- 1500M-3.6DBM; 2000M-4.0DBM; 2500M-2.8DBM; 3000M-1.8DBM; 3500M-3.6DBM
- Spectrum of the input frequency range of 138M-4.4GHz
- Frequency Accuracy (after calibration): +-1k @ 1GHz
- Low-noise input signal amplitude:-70DBM @ 0.5G
- Power: USB2.0, USB3.0 (+5 V/0.3A, it is best to pick USB3.0)
- Interface: USB2.0/ USB3.0, SMA
- Recommended tracking source (purchased separately) on our ebay shop.
- POWER:DC12V/0.5A
- Control software:WINNWT4
- Size::41*97*168mm(with N connect)
- Weight:500 g
Package Content:
- 1 x 138M-4.4G signal source signal generator/simple spectrum
- 1 x USB cable
- 2 x SMA cable
- 1 x DISC
- 1 x 40DB attenator
