Introduction:
- Black ordinary crystal
- The new XMOS XU208 program to support coaxial optical DOP output dsd64 PCM192KHZ 24Bit,I2S output DSD256,the use of acrylic crystal board to do under the cover.
1.XU208 use double gold PCB design (other models with more than the same is the tin spray design)
2.XU208 support IIS interface output DSD256 pcm384k SPDIF coaxial fiber output pcm 192khz dop64 (other with the same type of fiber output)
3.XU208 ordinary crystal optional patch or in-line can also be upgraded gold-plated crystal thermometer and Femtosecond CCHD957 (crystal and chip separate power supply can be compared with other models)
4.XU208 supports sampling frequency display f0 f1 f2 f3 dsd-pcm can display different sampling frequency (and other models with the same pcm dsd indication with sampling)
5.XU208 uses two ultra-low noise LDO lt1763 regulated supply price is adp 150aujz-3.3v voltage several times
6.XU208 output port with DSD on
7.XU208 supports external 5V dc power supply
8.PCB size: 100X60mm.
Each output interface supports the sampling rate:
- Optical Coaxial PCM: 44.1KHz,48KHz,88.2KHz,96KHz,176.4KHz,192KHz
- DSD: DOP64
- IIS: PCM: 44.1KHz,48KHz,88.2KHz,96KHz,176.4KHz,192KHz,352.8KHz,384KHz
- DSD: 2.8MHz (DSD64) - DoP, native;5.6 MHz (DSD128) - DoP, native;11.2 MHz (DSD256) native[Where I2S out supports full sample- rate,S/PDIF supports up to 192KHz and DOP DSD64]
- Bit Width: Up to 32 bit over I2S output;Up to 24 bit over S/PDIF
System compatibility:
1.Windows 7,Windows 8,Windows 10;32/64 bit,need to install special driver
2.Native MacOS 10.6 and later,using the system comes with drivers
3.Native Linux with UAC2 compliant kernel,using the system comes with drivers (tested on Ubuntu and Daphile systems,based on INTEL X86 platform)
4.Android OS 4.2 and above,you need the device to support the OTG function.Generally speaking,the system of Android 5.0 is supported by default.The following recommendations for 5.0 are compatible with the dedicated player (such as sea-shell player).
Package List:
- 1 x XMOS XU208 interface
