YINIU WD3 Hifi Bluetooth 5.1 Audio Receiver USB DAC Headphone Amplifier Dual PCM1794 For LDAC

YINIU WD3 Hifi Bluetooth 5.1 Audio Receiver USB DAC Headphone Amplifier Dual PCM1794 For LDAC

Features:
- DAC decoder with two PCM1794
- Bluetooth 5.1 for LDAC
- Support lossless playing for U disks
- Using imported audiophile components
- Five input ways including Bluetooth, U disk, PC USB, coaxial and optical
- Three output ways such RCA, XLR balanced output and 3.5 headphone jack
- USB sound card function supports computers, mobile phones, tablets and other devices. Through an USB OTG data cable, a mobile phone can be turned into a lossless digital turntable, so that the machine can decode high-quality sound. Support system for Android and Apple
- Bluetooth 5.1 enables 24bit 96Khz. Support for SBC, AAC, APTX, APTX-HD and LDAC lossless Bluetooth formats. Its sound clarity is improved by more than 30% compared to 5.0 Bluetooth
- User-friendly interfaces make it easier to use
- Digital lossless U disk playing. USB reading, DAC decoding and op amp output. Support 1TU disk/mobile hard disk. It uses a pure digital reading and DAC decoding circuit. The original music file of U disk is read by the USB chip, and then decoded and output by the PCM1794 chip, so that the lossless transmission of the signal and the high sound quality are guaranteed. Support WAV, APE, FLAC, MP3 and other lossless formats
- With an IR remote control to control the U disk playing function and the whole machine mode selection and switching function
- High-power headphone amp is suitable for 16-600 ohm headphones. Using high-current operational amplifier circuit, the maximum output power is as high as 800MW, and the deficient degree is as low as 0.003%. The sound is generous and wide, and high frequency, intermediate frequency and low frequency are balanced and durable. Suitable for earplugs and some high-impedance headphones such as K701 HD650
- Imported MUSES02 op amp and OPA2134*2
- Dual PCM1794 decoding chips reproduce the classic
- High-quality transformer made of pure copper

Specifications:
- Power supply: 110V or AC220V
- Size: 21 x 21 x 5cm/8.3 x 8.3 x 2"
- Bluetooth chip: QCC5125
- Decoding chip: PCM1794*2pcs
- Operational amplifier chip: MUSES02 + OPA2134*2
- Bluetooth format: For SBC, AAC, APTX, APTX-LL, APTX-HD and LDAC
- Coaxial/optical sampling rate: 24bit/192KHZ; 24bit/96KHZ
- Signal to noise ratio: about 121db
- Input interface: Bluetooth/optical/coaxial/U disk
- Output interface: RCA and XLR balanced output
- RCA output level: 3V

Package Included:
- 1 x Set of DAC Headphone Amp
