• YK86HB80-04A 86 2-Phase 4.6A 4.6N.m Reluctance Synchronous Stepper Motor for CNC

YK86HB80-04A 86 2-Phase 4.6A 4.6N.m Reluctance Synchronous Stepper Motor for CNC

Availability: In stock, usually dispatched in 1 business day

  • Price:$114.77
  • Price in reward points: 1148 Reward Points: 11
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $112.47 $110.18 $106.74 $102.15 Contact US
Quantity:

YK86HB80-04A 86 2-Phase 4.6A 4.6N.m Reluctance Synchronous Stepper Motor for CNC

Parameters:
- Step ange: 1.8 degree
- Body Length: 80mm
- Holding torque: 4.6N.m
- Current: 4.2A
- Resistance: 0.75Ohm
- Inductance: 3.4mH
- Rotor inertia g·cm²: 1400
- Weight: 2.3kg
- Motor Leads: 8
- Stepping accuracy: -+5%
- Temperature: 80 deg C Max.
- Environment temperature: -20~50 deg C
- Insulation resistance: 100MOhm Min.500V DC
- Voltage: 500V AC 1minute
- Radial clearance: 0.02mm (Max.) Loading 450g
- Rotor clearance: 0.08mm (Max.) Loading 450g

Package included:
- 1 x Stepper Motor
