ZHI LAI T2 Desktop Computer HiFi Decoder USB Sound Card Amp Fiber Coaxial Input DAC White

ZHI LAI T2 Desktop Computer HiFi Decoder USB Sound Card Amp Fiber Coaxial Input DAC White

Description:
- ZHI LAI T2 is a multi-function decoder which integrated decoder, fiber decoder, USB external sound card and amp.
- Can e used in computer, TV, digital disk, DVD player, lossless music player that with coaxial output or the output of fiber equipment.
- Support 4 types input signal: Analog signal, SPDIF digital coaxial signal, SPDIF digital optical fiber signal and USB signal
- In line with PCM format, supporting 48kHz, 88.2kHz, 96kHz, 16bit, 44.1kHz to 24bit of digital coaxial and digital optical fiber signal, with a fiber coaxial signal input switch.
- 192kHz 24bit DAC decoder chip PCM1793.
- USB chip PCM2706. Take its digital output to DAC decoding chip decoding to get a better effect, can be used as a high fidelity sound card to replace the original sound card.
- Aluminum case using CNC machining center, precision machining. The characters applies laser radium to carve, never fade.
- SPDIF for digital signal input file, USB is for USB signal input, W is for digital signal input, S for analog signal input
- COA OPT for the optical signal and the coaxial signal input switch. POWER for the machine power switch
- Nichicon, EVOX, RIFA capacitor, KOA resistance, NEC relay and the high quality of the high quality of the products, such as high - level audio dedicated components

Introduction:
1. USB sound card scheme: This machine realizes the receiving part of the sound signal through  PCM2706. Through the USB interface to receive the computer signal, the I2S output mode directly uses the DAC chip PCM1793 to make the sound decoding, through LineOut or the ear to expand the output sound.
2. DAC: Coaxial and optical fiber digital input. The digital signal receiving via the same axis to the CD/DVD device, you can make a sound decoding through the DAC chip PCM1793 of the machine, and the sound of the general CD/DVD turntable is significantly promoted! And the same can be connected to the output by LineOut to Headset external amplifiers or via headphone output.
3. Headphone Amp. Refer to the SOLO line and make improvements, in addition to the sound card, DAC's amp, but also connects a lot of equipment.
4. LAI T2 ZHI uses a special power amplifier as the core power supply single to double IC.  And it can supply power by connecting battery

Parameters:
Input
- USB input (support FULL 2 SPEED 48kHz, USB, 16bit)
- SPDIF RCA coaxial input (44.1kHz-96kHz, 16bit-24bit)
- SPDIF optical input (16bit-24bit, 44.1kHz-96kHz)
- Output: RCA block output, analog signal, about 2.0VRMS
- Distortion: < 0.0013% (A)
- Headset output level: PPmax:10V
- Headphone output matching impedance: 32 ohm; 600ohm
- Power supply mode: AC100V-240V (power adapter), DC12V (host)
- Color: White

Package included:
- 1 x ZHI LAI T2 Desktop Computer HiFi Decoder USB Sound Card Amp
- 1 x power adapter
- 1 x USB line one
- 1 x Headphone switch plug
